ASTERAS MAX 6X6-48
-
Description

Type of movementPulse motion with vibration
Technology 6×6
Construction materialCarbon Fiber Tube
Initial length2,50m – 3,00m
Type of headT8 aluminum counterweights with 48 carbon fiber sticks
Weight2,95kg
Rpm of the head2000 rpm @ 16V DC
Average consumption8A / hour
Motor14-16V/ 400W
28-30V/ 400W *concerns 24V motors
Cable length15m
Output200 – 250kg olive seed
Power supplyGenerator or battery (80A – 100A) with converter
MOVEMENT
With the NEW SYSTEM (Independent movement of the spheres) 4×4 and 6×6 is achieved:
- It move freely in the densest parts of the olive tree
- Minimize damage to fruits and olives
- Relaxed usage after transferring zero vibrations to the user.
The olive harvester Asteras Max is a Greek machine with 2 heads and 48 carbon fiber sticks.
The unique layout of carbon fiber along with the wide range balanced pulse motion, achieves maximum performance without the slightest damage on the tree

HEAD
ASTERAS MAX is 100% made in Greece with a patented mechanism of our invention, which is an olive picking machine with T8 aluminum counterweights
48 carbon fiber sticks,
2 eccentric T8 aluminum counterweights
* Ability to add 4×4 or 6×6 system to all types of Astera
Evolving our company’s best seller ASTERAS CF even more, we added an additional bar with 8 sticks for maximum range, and even greater efficiency. The unique arrangement of the sticks, combined with the elasticity of the head, result in the creation of the ultimate tool for harvesting olives.


MOTOR
- It has an electric motor BOSCH DC 400W with an output of 2000 pulses per minute at 16V
- Features an ON-OFF switch 35A and a head-to-pulse gear reducer
- It also works with a car battery (WITH ADDITIONAL CONVERTER). with consumption 10-12 A / HOUR
- Comes with cable 15 meter
Useful Information
-
