| item | parameter |
| MODEL | LY1100/B € |
| STRUCTURE | front-mounted |
| ENGINE MODEL | 178FA/186FA/188FA Gasoline engine |
| RATED POWER | 4.0KW/6.3KW/6.7KW |
| DIMENSION (L×W×H) | 1620×1050×900/1789×990/1800×970×990MM |
| WEIGHT | 141KG/168KG/158KG |
| TRANSMISSION MODE | Gear transmission |
| CONNECTION MODE | Direct connection |
| HORIZONTAL | 360 |
| VERTICAL | 120 |
| ROTATE SPEED | 1 gear 84.5R/MIN 11 gear 145.1r/min |
| MAX. TUMING RADIUS | 185 MM. 195MM |
| NUMBER OF BLADES | 24/32/40 |
| MODEL OF ROTARY BLADE | 185MM, 195MM |
| MAIN CLUTCH TYPE | friction disc |
| TILLING WIDTH | 1050-1350MM |
| TILLING DEPTH | >100MM |
| OPERATING SPEED | >0.3M/S |
| PRODUCTIVITY | 0.1-0.2HM(H.M) |
| FUEL CONSUMPTION | < 10KG/HM |
| WHEEL SIZE | 400-8/400-10/500-12/600-12 |
